DS-K2M060 Unidad de de control de puerta/cerradura
Nota: en imagen uso típico del modelo
La unidad de control de puerta segura es la intermediaria entre el terminal de control de acceso y la cerradura (de tipo magnético, cerradura o el botón de salida, etc) Se puede aplicar para mantener la puerta cerrada cuando la puerta está dañada
- Communicate swith the access control terminal via RS-485 to execute the commands from the terminal including open door, close door, normally open and normally closed
-Collects the door magnetic signal, the exit button signal and the tamper-proof signal and send them to the access control terminal
-Supports tampering Alarm
-Supports RS-485 communication indicators to show the communication status
-4 ch DIP switch supporting ID NO. configuration
-Supports a Wiegand interface to connect a Wiegand card reader to enter/exist access control terminal by swiping card
| Device Interfaces |
| Communication Mode: |
|
RS-485 |
| Output Interface: |
|
Lock*1, Alarm Out*1 |
| Input Interface: |
|
Exit Button*1, Door Magnetic*1, and
Wiegand*1 |
| General |
| Power Supply: |
|
12VDC |
| Indicator: |
|
7 Indicators (RS-485 Communication Status*2, Power Supply*1,
Exit Button*1, Lock Status*1, Door Magnetic*1 and Running
Status*1) |
| Installation: |
|
Wall Mounting |
| Working Humidity: |
|
10% to 90% (Non-Condensing) |
| Working Temperature : |
|
-30°C to +55°C (-22°F to 131°F) |
| Dimensions (L×W×H): |
|
48mm × 115mm × 25mm (1.89'' × 4.53'' × 0.98'') |
