| Camera |
| Image Sensor: |
| |
1/1.8″ Progressive Scan CMOS |
| Signal System: |
| |
PAL/NTSC |
| Min. Illumination: |
| |
Color: 0.002 Lux @ (F1.2, AGC ON)
B/W: 0.0002 Lux @ (F1.2, AGC ON) |
| Shutter time: |
| |
1s ~ 1/100,000s |
| Slow shutter: |
| |
Support |
| Lens Mount: |
| |
C/CS mount |
| Auto Iris: |
| |
DC drive(-P: support P-Iris) |
| Day& Night: |
| |
IR cut filter with auto switch |
| Wide Dynamic Range: |
| |
120 dB |
| Digital noise reduction: |
| |
3D DNR |
| Focus: |
| |
ABF(-A model) |
| Compression Standard |
| Video Compression: |
| |
H.264+/H.264/MPEG4/MJPEG |
| H.264 code profile: |
| |
Baseline Profile / Main Profile / High Profile |
| Video bit rate: |
| |
32Kbps~16Mbps |
| Audio Compression: |
| |
G.711/G.722.1/G.726/MP2L2 |
| Audio bit rate: |
| |
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Triple Streams: |
| |
Yes |
| Image |
| Max. Image Resolution: |
| |
1920 x 1080 |
| Frame Rate: |
| |
50Hz: 50fps(1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Third Stream: |
| |
Independent with Main Stream and Sub Stream, up to
50Hz: 25fps(1920 × 1080); 60Hz: 30fps (1920 × 1080) |
| Image Enhancement: |
| |
BLC/3D DNR/ROI/Defog/EIS |
| Image Settings: |
| |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| Target Cropping: |
| |
Support |
| Picture Overlay: |
| |
LOGO picture can be overlaid on video with 128×128 24bit bmp format |
| Day/Night Switch: |
| |
Auto/Schedule/Triggered by Alarm In |
| Network |
| Network Storage: |
| |
NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger: |
| |
Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
| Protocols: |
| |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General Function: |
| |
User Authentication, Watermark, IP address filtering |
| System Compatibility: |
| |
ONVIF (Profile S, Profile G),ISAPI |
| Interface |
| Audio: |
| |
1-ch 3.5 mm audio in( Mic in/Line in)/out interface, 1 build-in Microphone |
| Audio Input: |
| |
1-ch 3.5 mm audio interface, Mic in/Line in. 1 built-in Microphone |
| Audio Output: |
| |
1-ch 3.5mm audio interface |
| Communication Interface: |
| |
1 RJ45 10M/100M Ethernet port, 1 RS-485 interface and 1 RS-232 interface |
| Alarm: |
| |
1 input, 1 output (up to DC24V 1A or AC110V 500mA ) |
| Video Output: |
| |
1Vp-p Composite Output (75 Ω, BNC) |
| On-board storage: |
| |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Reset Button: |
| |
Yes |
| Audio |
| Environment Noise Filtering: |
| |
Support |
| Audio I/O: |
| |
Support dual audio track, stereo |
| Audio Sampling Rate: |
| |
16kHz / 32kHz / 44.1kHz / 48kHz |
| Smart Feature-set |
| Behavior Analysis: |
| |
Line crossing detection, Intrusion detection, Region entrance, Region exiting, Unattended baggage, Object removal |
| Line Crossing Detection: |
| |
Cross a pre-defined virtual line |
| Intrusion Detection: |
| |
Enter and loiter in a pre-defined virtual region |
| Region Entrance: |
| |
Enter a pre-defined virtual region from the outside place |
| Region Exiting: |
| |
Exit from a pre-defined virtual region |
| Unattended Baggage: |
| |
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Object Removal: |
| |
Objects removed from the pre-defined region, such as the exhibits on display. |
| Exception Detections: |
| |
Scene change detection, Sudden audio increase/decrease detection, Audio loss detection, Defocus detection |
| Recognition: |
| |
Face detection recognition |
| Statistics: |
| |
Object Counting (Entrance and Exit object number is accounted and showed on screen in real time) |
| General |
| Operating Conditions: |
| |
-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing) |
| Power Supply: |
| |
24VAC± 10%, 12 VDC ± 10%, PoE (802.3af) |
| Power Consumption: |
| |
Max. 6 W (Max. 9W with IR cut filter on) |
| Dimensions: |
| |
69.8×58×145 mm (2.75” × 2.28” × 5.71”) |
| Weight: |
| |
830 g (1.83 lbs) |
