General
SSID SecurityWPA2 (802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK, Open
Max Phy Rate2.4 GHz radio: 300 Mbps 5 GHz radio: 867 Mbps
Max EIRP2.4 GHz: 25 dBm 5 GHz: 25 dBm
Controller modesController-less standalone AutoPilot heterogeneous network Cloud managed cnMaestro On-premises cnMaestro VM
WLAN100 clients, 16 SSIDs WPA-TKIP, WPA2 AES, 802.1x 802.11w PMF
Captive PortalHosted on cnMaestro Controller On-AP hosted guest portal Redirect to HTTP/RADIUS Server DNS logging
AuthenticationHotspot 2.0/Passpoint 2.0 802.1x EAP-SIM/AKA, EAP-PEAP, EAP-TTLS, EAP-TLS MAC authentication to local database or external RADIUS
AccountingYes. Supports RADIUS based accounting to multiple AAAs
Scheduled SSIDTurn SSID ON/OFF on a daily/weekly/time of day basis
Guest AccessVouchers, Rate Limit, Splash page hosted on AP or cnMaestro Client isolation per SSID, per network
Time/Data LimitTime, Rate, Throughput limit per SSID
Subscriber QoSWMM, client isolation network wide
Fast Roaming802.11r, OKC, Enhanced roaming
MeshMulti-hop, either band
Channel SelectionautoTune: Manual, or automatic Selectable off-channel scan
TunnelL2TP, L2oGRE, PPPoE
ToolsRemote Packet capture, Channel/noise/interference analyzer, auto logging, ZapD performance test tool, rogue AP detection
ServicesNTP, Syslog, SNMP traps, DNS proxy, auto-off on WAN failure
Opciones de implementación a prueba de manipulaciones
Mount OptionsStandard mount single gang J-box bracket included. Dual gang J-box bracket and flush box optional
Physical EnvironmentalUSB 2.0 147mm x 94mm x 32mm 268g Kensington lock slot, secure bracket Tri-color status LEDs 0C - + 40C ambient op temp -40C - + 70C storage temperature 95% RH non-condensing MTBF: 249k @ 45c
CertificationsWiFi Alliance 80211a/b/g/n/ac, PP2.0 in process FCC, ETSI, CE, EN 60601-1-2, IEC60950
